Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade

    Buy cheap Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade from wholesalers

    Buy cheap Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade from wholesalers
    • Buy cheap Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade from wholesalers
    • Buy cheap Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade from wholesalers
    • Buy cheap Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade from wholesalers
    • Buy cheap Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade from wholesalers

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade

    Ask Lasest Price
    Brand Name : KAIYAMEI
    Model Number : KA-AC1653
    Certification : ISO9000, ISO9001,ISO14000,CQC,RoHS,Testing Reports
    Price : USD1.6-3.3/Kilogram
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 8000 TONS/MONTH
    Delivery Time : 15-35 DAYS
    • Product Details
    • Company Profile

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade


    Product Description
    The aluminium curtain wall system is simple to set up and mount, but unprecedented in the
    number of possibilities,which include:type of water drainage,compartment or channel drainage,
    and which cover strips to use for the outside of the facade.
    Within it is also possible to construct a (semi-) structural facade.The inside construction will be the same in any case.
    Product Description
    Brand Name:Curtain wall extrusion aluminum profiles
    Material:Ranging from 1000 series to 7000 series, normal material such as 6063,6005,6061,6060, special materials such as 6082, 7005, 7075 etc.
    Thickness:General profiles thickness: 0.8 - 5.0 mm; Anodized protection thickness: 8 - 25 um; Powder coating color thickness: 40 - 120 um.
    ColourSilver, bronze, black, gold, blue,grey, champagne, bright, as your requests.
    Temper:T3-T8
    Shape:square, flat, round, hollow, oval, triangle, U-profiles, L-profiles, T-profiles, H-profiles, customized available
    Surface Treatment:Mill finish, anodic oxidation,power coating,eletrophoresis, PVDF coating,
    all kinds of high simulation wood grain processing, etc.
    Products Classification:
    1) General aluminum profiles:
    various shapes of pipes and tubes, angles,T or U shapes etc.
    2) Industrial aluminum profiles:
    clothes-horse, goods shelves and racks, heat sink, enclosures of chargers. closet frame, furniture frames, LED lighting, Ads screens frame, protect fences, Ladder, Guide Rail, Pipeline Integration etc.
    3) Construction aluminum profiles:
    Aluminum doors& windows, Sliding Windows, Roller shutter door,Curtain track, etc.
    4) OEM & ODM:
    accept customers' own designs and drawings of aluminum products
    Deep processing:Cutting,punching,drilling,tapping,milling,bending,welding etc.
    Manufacture
    technological process:
    Aluminium ingot →Melting and casting→Homogenizing →Extrusion→Aging→Powder coating→Pouring rubber for heat insulation→Acceptance test→Packing→Warehouse→Delivery.
    Certification:ISO 9000;ISO 9001;ISO 14000;CQC;RoHS;
    Markets we sold:Australia, Germany, North America, Africa, and European countries and area.

    Alloy6063(%)6061(%)6082(%)
    Silicon Si0.20~0.600.40~0.800.7~1.2
    Iron Fe0.350.700.5
    Copper Cu0.100.15~0.400.1
    Manganese Mn0.100.150.4~0.8
    Manganese Mg0.45~0.900.18~1.20.6~0.8
    Chromium Cr0.100.04~0.350.25
    Zine Zn0.100.250.2
    Titanium Ti0.100.150.1
    Others(each)0.050.050.05
    Others0.150.150.15
    AluminumRemainderRemainderRemainder

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel FacadeCurtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel FacadeCurtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel FacadeCurtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel FacadeCurtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade





    FAQ

    Q: What’s the thickness for anodizing? Can you do 15um?

    A: Our normal thickness is about 10 um. Yes, we can do 15um and above.


    Q: What color you can do for powder coating? The thickness for powder coat?

    A: We can do any color for powder coat as long as you can provide the color sample. Our normally powder coating thickness is 60-80um.


    Q: What color you can do for wood grain?

    A: Our most popular colors are Western Red Cedar, Australia Cedar, Jarrah I, Jarrah II, Chestnut, Bush Cherry, Bush Wood, Western Wood, Snow Gum, etc. If you need any other colors, we can do according to the color samples you provide.


    Q: What’s the delivery time for samples and mass production?

    A: (1). 2-3 weeks to open the new mold and make samples.

    (2). 3-4 weeks after receipt of deposit and confirmation of the order.


    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade


    About us :


    Foshan Kaiya Aluminum Co., Ltd is a comprehensive and professional enterprise integrating research, design production and sales of aluminium extrusion profiles for construction and industrial applications. There are currently 24 aluminum extrusion process lines at 500MT TO 2500MT, 5 process lines for anodizing, 3 process lines for powder coating, 2 process line for painting, 2process line of polishing and brushing. We still have 2 packing line. Our annual production capacity has reached 80,000 tons which is at the forefront of the aluminium industry in China.

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel FacadeCurtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade

    Curtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel FacadeCurtain Wall Structure Aluminium Alloy Profile For Double Glazing Glass Panel Facade
